20W Raycus Fiber Laser Marking Machine
Basic Info
Model No.: VLF10/20/30M
Product Description
20W Raycus Fiber Laser Marking Machine
VLF-10/20/30M Fiber Laser Marking Machine suitable for Gold, Silver, Diamond, Sanitary Equipments, Foods Packing, Tobacco Label, Beer label, Drink Label, Medicine Packing, Glasses and Clock, Auto Parts, Plastic& Paper Materials, The Electron, Hardware which with high request for depth, smooth,accuracy such as horologe, Mould, bitmap marking etc.
Parameter List
Laser power | 10Watt/20Watt/30Watt |
Laser source | Raycus/IPG/JPT Fiber |
Light wave length | 1064nm |
Laser modulation mode | Coupling amplification |
Marking area | 70x70mm/110x110mm/175x175mm/200x200mm/300x300mm Optional |
Work table size | 150x210 mm |
Max marking speed | 7000mm/s |
Marking depth | 0.05~0.5mm(acc. to material) |
Min linewidth | 0.01mm |
Min marking character | 0.2mm |
Impulse frequency | 20~250kHz |
Cooling way | Air cooling |
Power supply | 220V/50Hz/1kVA |
Min focus facula diameter | 20um |
Re-position accuracy | 0.0025mm |
Laser indicator | Red dot pointer |
1.20W Raycus Fiber Laser Source
2.Original EZCAD software (support windows 10)
3.Easy -focus device
4.High Precision Galvanometer scanning
Samples Show
More Products
Package
Packaging | |
Size | 850 (L) * 760 (W) * 800 (H)/MM |
Weight | 78KG |
Packaging Details | Complying With The Export Packing Standard Wooden Boz, Sea- Worthy or Air- Worthy |
Company Information
Jinan Vmade CNC Machine Co.,Ltd was established in 2010. Located in hightech zone.It is a professional team which specialized in Optic, Electricity, Mechanics. Vmade keep delicate and attentive attitude on every step and always keep to learn the most advanced technology and create more humanized products to all our customers.
Contact Information
Please tell us what you need!!
1.What is your working size?
2.What material do you need to cut/engrave?
3. What is the thickness and size of each materials?
4.What is your business industry? signage or art craft works or what else ?
Below My contact information:
Product Categories : Laser Marking Machine > Raycus Fiber Laser Marking Machine
