1*32 PLC switch Splitter

Product Description

    1*32 PLC switch Splitter1*32 PLC switch Splitter  Company Information   Our company is a high-tech enterprise which is devoted to developing and manufacturing optoelectronic devices and providing technical services,  mainly produce all kinds of Ceramic Ferrule, fiber optic connector and pigtails, adapter, splitter,attenuator, optical filter, optical collimator, which have been approved by ROHS,TLC certificate, company management passed OHSMS standard.   Product Description   Features Low Insertion loss and high return loss Low PDL Compact Design Good channel-to-channel uniformity Wide Operating Wavelength: From 1260nm to 1650nm Wide Operating Temperature: From -40°C to 85°C High Reliability and Stability   Applications FTTX Systems PON Networks CATV Links Optical Signal Distribution   Compliance Telcordia GR-1209-CORE Telcordia GR-1221-CORE RoHS   Specifications 1×N PLC Splitter

Parameters

1×2

1×4

1×8

1×16

1×32

1×64

1×128

Operating Wavelength (nm)

1260~1650

Fiber Type

G657A1 or customer specified

Insertion Loss (dB)(P/S Grade)

 3.8/4.0

 7.1/7.3

10.2/10.5

13.5/13.7

16.5/16.9

20.5/21.0

23.8/24.2

Loss Uniformity  (dB)

0.4

0.6

0.8

1.2

1.5

2.0

2.5

Polarization Dependent Loss(dB)

0.2

0.2

0.2

0.25

0.3

0.35

0.4

Return Loss (dB)(P/S Grade)

55/50

55/50

55/50

55/50

55/50

55/50

55/50

Directivity (dB)

55

55

55

55

55

55

55

Wavelength Dependent Loss (dB)

0.3

0.3

0.3

0.5

0.5

0.5

0.5

Temperature Stability

(-40~85 °C)(dB)

0.4

0.4

0.4

0.5

0.5

0.5

0.5

Operating Temperature (°C)

-40~85

Storage Temperature (°C)

-40~85

Device Dimension (mm)

40×4×4

40×4×4

40×4×4

50×4×4

50×7×4

60×12×4

N/A

Module Dimension (mm)

100×80×10

100×80×10

100×80×10

120×80×18

140×115×18

140×115×18

140×115×18

Mini-Module Dimension (mm)

50×7×4

50×7×4

50×7×4

60×12×4

80×20×6

100×40×6

N/A

Notes: 1.  Specified without connectors. 2.  IL will be 0.15dB higher with connectors. Application 1*32 PLC switch Splitter  Related products 1*32 PLC switch Splitter
