3 Ports 100G 200G 1X2 DWDM Device for Fiber Optic Filter

SUNSHINE'S 100GHz/200GHz 1x2 wavelength multiplexer utilizes thin film coating technology and proprietary design of non-flux metal bonding micro optics packaging to achieve optical add or drop at a ITU wavelength. It provides ITU channel center wavelength, low insertion loss, high channel isolation, wide pass band, low temperature sensitivity and epoxy free optical path . It can be used for wavelength add/drop in telecommunication network system.

Features of DWDM devices

1)Low Insertion Loss

2)Excellent Channel Isolation

3)High Stability & Reliability

4)Low Cost

5)ITU Compliance

Applications

DWDM Channels Add/Drop
DWDM Network & Systems
EDFA Application Systems
Accessing WAN Networks
Long Haul Network & Systems
